Silicone Rubber Keypad Panel Membrane Switch

MOQ : 100

HS Code : 8536500000

Operation Temperature : -104°F~158°F

Production Capacity : 100, 000/Month

Model NO. : HC-SRK-015

Rated Voltage : <50V, DC

Dome springback time : <5 msec

Tactile type : 0.3-1.5mm

Wire lead resistance : <1Ω/CM

Life time : >1 Million times

Switch travel : Flat Type 0.05-0.3mm

Rated current : 25-100mA,0~30V DC

Operation Humidity : at104°F,<98%RH

Base Material voltage : 1500 V DC

Tail flexibility : any angle within 180 degree

Insulation resistance : <100MΩ,250V DC

Contact Now

Silicone Rubber Keypad Panel Membrane Switch

With over ten years of design and manufacturing experience in membrane switches and silicone rubber keypads, we deliver reliable solutions for demanding applications.

Industry Applications

Our products are widely used in electronics, appliances, medical equipment, and automotive systems, serving more than 100 satisfied customers worldwide.

Technical Specifications

Wire Lead Resistance	<1Ω/CM	Life Time	>1 Million cycles
Rated Current	25-100mA, 0~30V DC	Operation Temperature	-104°F to 158°F
Rated Voltage	<50V, DC	Operation Humidity	at 104°F, <98% RH
Insulation Resistance	<100MΩ, 250V DC	Dome Springback Time	<5 msec
Switch Travel	Flat Type: 0.05-0.3mm Tactile Type: 0.3-1.5mm	Base Material Voltage Withstand	1500 V DC
Tail Flexibility	Any angle within 180 degrees
