Silicone Rubber Keypad 2

MOQ : 1

Switch travel : Flat Type 0.05-0.3mm

Specification : 20g

Life time : >1million times

Insulation resistance : <100MΩ,250V DC

Dome springback time : <5 msec

Operation Temperature : -40ºC~70ºC

Material : PET /PC

Adhesive : 3M467 & 3M468

Price : 1.5

Model NO. : TKM224

Transport Package : 10PCS

Production Capacity : 50000000/Year

Rated current : 25-100mA,0~30V DC

Operation Humidity : at40ºC,<98%RH

Rated Voltage : <50V, DC

Wire lead resistance : <1Ω/CM

Contact Now

Silicone Rubber Keypad 2 - Professional Membrane Switch

High-quality membrane switch with tactile feedback, designed for reliable performance across various industrial applications.

Key Features

Membrane Switch with integrated windows
Tactile feedback keys with embossing
High-quality silk screen printing
Exceptional durability: Over 1 million life cycles
Flexible options: Metal dome or silicone keypad available

Product Information

Place of Origin: Dong Guan, China
Brand Name: Foundation
Model Number: HC-MS-003
Certification: ISO9001:2008, SGS, Rohs

Material Specifications

Material: PET / PC
Adhesive: 3M467 & 3M468 or custom options available
High lifetime: >1 million cycles
Certifications: ISO9001:2008, RoHS, SGS
Premium quality construction

Commercial Terms

MOQ: 100pcs
Payment Terms: T/T or L/C
Mold Charge: 100% in Advance
Sample Time: 9-10 days after drawing approval
Production Lead Time: 15-22 days after sample approval

Applications

Medical Equipment
Telecommunications Apparatus
Telephone Systems
Household Appliances
Security Systems
Industrial Controls

Technical Specifications

Parameter	Specification	Parameter	Specification
Wire Lead Resistance	<1Ω/CM	Lifetime	> 1 Million times
Rated Current	25-100mA, 0~30V DC	Operation Temperature	-40ºC ~ 70ºC
Rated Voltage	<50V, DC	Operation Humidity	at 40ºC, <98%RH
Insulation Resistance	<100MΩ, 250V DC	Dome Springback Time	<5 msec
Switch Travel (Flat Type)	0.05-0.3mm	Base Material Voltage Withstand	1500 V DC
Switch Travel (Tactile Type)	0.3-1.5mm	Tail Flexibility	Any angle within 180 degree

Company Advantages

Experienced top management with extensive field expertise

Professional staff and skilled workforce

Strong research and development capabilities

Quick delivery and reliable turnaround times

Competitive pricing structure

Two factories available for large order capacity

Expert sales team and exceptional customer service
